日本***混泥土输送泵
日本川崎KRC-3500D/SD混泥土泵
混泥土泵为车管式，型号为：KRC-3500D/SD
CONCRETE PUMP ( POMPA BETON)
These days, a rising difficulty in the concrete application industry is transporting the concrete to access small street, crowded locations, islands, mountains, towers, and other similar cases which requires the pump to be attached in high places using helicopters or ropeways. Anticipating cases like these, we have managed to develop portable and light pumps, utilizing rotation pump systems to improve usages
KRC-3500-D 2t Piping Car
Max Discharge: 35 m?/h
Max Horizontal Transfer Distance : 200m
Max Vertical Transfer Distance : 30m
Max Aggregate Size : 25mm
PUMP | |
Type | KRC-3500-D |
method | Squeeze Method (All Hydraulic Contro) |
Max Discharge Volume | 35 m?/h |
Max Transfer Distance | 200m(Horizontal) / 30m (Vertical) |
Max Aggregate Size | 25mm (or Less) |
Slump | 12cm (or Over) |
Piping Diameter | 100A |
Hopper Capacity | 300 litter |
Ground level of Hopper 930mm | 1,080mm |
OPE | |
(NORMAL, STOP, REVERSE) | (Manual Possibility) |
Control of Discharge | (Manual Possibility) |
Agitator Feature | Hydraulic Lever |
Cleaning Method | One person is enough for flushing |
Water Tank Capacity | With water Pump (300 litter) |
Type | ISUZU 2t Truck |
Engine Power | 110HP |
Seat | For 3 Persons |
The volume of discharge and transferring distance is influenced by the various conditions of cement.
Options = Air Conditioner
Standard Attachment
Hose for Root 100?x2m | 1 |
Pipe 100?x1m | 1 |
Pipe 100?x1.5m | 2 |
Pipe 100?x3m | 15 |
Bent Pipe 100?x90° | 2 |
Bent Pipe 100?x45° | 2 |
Bent Pipe 100?x22° | 2 |
Tip of Hose 100 ?x8m | 1 |
Joint | 25 |
Cleaning Sponge | 5 |
Pumping Tube | 1 |
Tool Kit | 1 |
