| 品牌： | 日本川崎 | 型号： | KRC-3000 |
|---|---|---|---|
| 产品别名： | / | 用途： | / |
| 适用行业： | / | 产品用途： | / |
| 规格： | / |
日本川崎KAWA混泥土泵 日本***混泥土输送泵 日本川崎KRC-3000混泥土泵
混泥土泵为固定式，型号为：KRC-3000
CONCRETE PUMP ( POMPA BETON)
These days, a rising difficulty in the concrete application industry is transporting the concrete to access small street, crowded locations, islands, mountains, towers, and other similar cases which requires the pump to be attached in high places using helicopters or ropeways. Anticipating cases like these, we have managed to develop portable and light pumps, utilizing rotation pump systems to improve usages
KRC-3000-1 (Stationary Type)
Max Discharge : 30 m?/ h
Max Horizontal Transfer Distance: 200m
Max Vertical Transfer Distance : 30m
Max Aggregate Size : 25mm
PUMP | |
Type | KRC-3000-1 |
Method | Squeeze Method (All Hydraulic Control) |
Max Discharge Volume | 30 m?/h |
Max Transfer Distance | 200m(Horizontal) / 30m(Vertical) |
Max Aggregate Size | 25mm (or Less) |
Slump | 12cm (or Less) |
Piping Diameter | 100A |
Hopper Capacity | 200 litter |
Ground Level of Hopper | 820mm (Measurement With Wheel) |
OPE | |
Pump(Normal,Stop,Reverse) | Hydraulic Lever |
Pump(Control of Discharge) | Accelerator Lever |
Agitator Feature | Hydraulic Lever |
Cleaning method | One person is enough for flushing |
Power (pump) | Diesel Engine (57HP) |
Measurement H x W × D | 1,380 × 1,250 × 2,800 (mm) |
Weight | 1800kg |
Remote Control
Type : (For Pump: Normal – Stop – Reverse / And for Discharge Volume)
Water-Tank (300 litter) for cleaning /And Water pump (12V)
Self-propelled Type
Standard Attachment
Hose for Root 100?x2m | 1 |
Pipe 100?x1m | 1 |
Pipe 100 ?x1.5m | 2 |
Pipe 100?x3m | 15 |
Bent Pipe 100?x90° | 2 |
Bent Pipe 100?x45° | 2 |
Bent Pipe 100?x20° | 2 |
Tip of Hose 100?x8m | 1 |
Joint | 25 |
Cleaning Sponge | 5 |
Pumping Tube | 1 |
Tool Kit | 1 |
The above transferring terms and conditions are applied for in case of more than 300kg cement, slump is18 ~ 22cm.
The volume of discharge and transferring distance is influenced by the various conditions of cement.
