| 是否进口： | 否 | 产地： | / |
|---|---|---|---|
| 加工定制： | 是 | 品牌： | 瑞典Friborg |
| 型号： | 5202 | 类型： | 电器撞击检测设备 |
| 外形尺寸： | /mm | 重量： | /Kg |
| 产品用途： | 撞击检测设备 | 规格： | / |
电器撞击检测设备报价 进口IEC60065电器撞击检测设备
撞击检测设备根据IEC60065条12.1.1的标准，对电视机等电器的跌落测试.
Bump Test Equipment Model:5202
Reference to IEC:60065, clause 12.1.1
This tester generates fall-down tests of, e.g. TV sets. The TV set stands on a platform which falls down 50mm rapidly. The TV set therefore has a free fall of 50mm. The test equipment is floor standing and consists basically of:
Simulate 50 times free falls from a height of 50 mm onto a wooden table
The TV set is standing on a wooden surface. By using pneumatic
cylinders the surface falls down rapidly and upwards slowly
3. The equipment has a counter with automatic stop at pre set amount of cycles totally 50 falls
4. The cycling movement up and down is controlled by a timer Compressed air supply: 8 bar - no higher pressure is allowed
5. Start/stop button
6. Certificate issued by Friborg Test Technology
7. Weight: App. 80 kg
8. Dimensions: App. 1000x1000x700 mm (LxWxH) + 500x400x300mm (LxWxH, Pneumatic Box)
9. Supply：115/230 VAC, 50 Hz, Compressed Air 6 bar.
